Abnormal Testing

    Product List
  • Hipot Testing
  • Ground Continuity Testing
  • Leakage Current Testing
  • Accessibility Probes
  • Impact Testing
  • Temperature Measurement
  • Voltage, Current, & Power Management
  • Force & Torque Management
  • Power Control
  • Loading Devices
  • Flame & Other Plastics Testing
  • IP Code Testing
  • Plug, Socket, & Cord Testing
  • Breaking Capacity Testing
  • Abnormal Testing
  • Environmental Testing
  • Creepage & Clearance Testing
  • Toy Testing
  • Other Safety Products
  • Safety Labels
  • Uncategorized
Home / Abnormal Testing
  • Model KS Knife Switches

    Read more
  • Model ACC-01 Cheesecloth

    Read more
  • Model ATP-01 Tissue Paper

    Read more
  • Model ACG-01 Cotton Gauze

    Read more
  • Model ACP-01 Cotton Pad

    Read more

Model KS Knife Switches

Product Details
Single Throw, Fusible Single Throw, and Double Throw types available with 1, 2, 3 or 4 poles. Perfect for open circuit and short circuit component fault testing! Corrosion resistant contacts with insulating base. Rated 30A.
    Meets Requirements for Testing Standard(s) including but not limited to:
  • IEC 60601
  • IEC 60950
  • IEC 61010
  • EN 60950

Model ACC-01 Cheesecloth

Product Details
This product is used to test for the possibility of ignition. It is required by International and USA standards such as IEC, UL and CSA. To be placed on tissue paper and then covered with cheesecloth as the indicator of a fire hazard during abnormal tests (component fault, motor locked rotor, fan failure, etc...). Cheesecloth is untreated cloth running 14-15 yd.2/lb. (26-28m2/kg.) and a thread count of 32 by 28 per most standards. Cheesecloth comes in 36 in. x 5 yd. lengths.
  • Made of untreated cotton with 12.6 by 11.0 threads per cm (32x28 threads per inch)
  • Weights between 35.7-38.5 grams per square meter(1.06-1.14 oz (per square yard)
  • Minimum width of material is 0.914 meters (1 yard)
  • Minimum length of product is 4.572 meters (5 yards)
    Meets Requirements for Testing Standard(s) including but not limited to:
  • IEC 60601
  • IEC 60950
  • IEC 61010
  • UL 1703
  • EN 61010
  • EN 60950

Model ATP-01 Tissue Paper

Product Details
This tissue paper is undyed, strong, lightweight tissue paper weighing 12-30 grams per square meter. Tissue paper comes in packages of ten sheets each measuring 20x25 in.
    Meets Requirements for Testing Standard(s) including but not limited to:
  • IEC 60601
  • IEC 60950
  • IEC 61010
  • EN 61010
  • EN 60950

Model ACG-01 Cotton Gauze

Product Details
4.5 in. X 10 ft. roll, 1/32 in. thick Cotton Gauze Dry, absorbent, white, untreated, surgical grade, 100% cotton gauze. Material has a loose weave; air passes freely through it.

Model ACP-01 Cotton Pad

Product Details
6.0 in. X 16 in. Cotton Pad Dry, absorbent, white, untreated, 100% cotton pad. Surgical grade, 1-inch thick cotton; air will not easily pass through this material.
